Evaporative Cooling High Temperature Chiller
Internal Indirect Evaporative Cooling High Leaving Temperature Chiller
An energy-efficient chiller using internal indirect evaporative cooling, modular design, intelligent control and 3D water distribution — over 65% energy savings compared with mechanical refrigeration.
Applications
Features
- Saves 65%+ energy vs. mechanical refrigeration
- Flame-retardant, antibacterial polymer filler; quick to replace
- DC brushless EC fan
- PLC + touchscreen with automatic fan speed
- Stainless steel tank with quick-access port
- Wide-spaced plate indirect cooling core
- Anti-clog 3D water distribution
- Full protection and alarms
Optional functions
- Intelligent group control for up to 40 units
- Water softening system for hard-water areas
- Built-in plate exchanger and primary pump system
- Built-in mechanical refrigeration backup
- Circulating water descaling, filtration and sterilization
- Antifreeze device for the water tank
- Lightning and surge protection
Specifications
| Model (single module) | Max circulating water (m³/h) | Supply/return ΔT (°C) | Max power (kW) | Max noise dB(A) |
|---|---|---|---|---|
| AGS40 | 40 | 3/5/10 | 18 | 74 |
| AGS50 | 50 | 3/5/10 | 22 | 75 |
| AGS80 | 80 | 3/5/10 | 35 | 78 |
| AGS100 | 100 | 3/5/10 | 41 | 80 |
| AGS150 | 150 | 3/5/10 | 62 | 82 |
| AGS200 | 200 | 3/5/10 | 80 | 85 |
Specific performance, dimensions and non-standard customization are available from our technical team.
How it works
