Features
1. Compact structure,more durable and reliable.
2. Wall-mounted installation, beautiful and elegant.
3. Large-angle air supply, wide air supply range.
4. There are three wind speeds to choose from.
5. Low noise, soft and comfortable wind.
Application
Dormitories, school cafeteria , shops, restaurants, families, etc.
Specification
| Model | AZL06-ZC13B |
| Airflows (m³/h) | 6000 |
| Pressure(pa) | 60 |
| Power (Wtts) | 150 |
| Voltage/Frequency | 220V/60Hz |
| Rated Currncy(A) | 1.25 |
| Maximum Output Power | 0.15KW/h |
| Fan Type | Axial Fan 3-Speeds |
| Fan Blade Type | 4-Blade Plastic Propeller |
| Cabinet Material | 100% virgin PP Plastic |
| Air Diffuser | Air Diffuser Automatic Swing |
| Water Lack sensor | √ |
| Grounding Protection | √ |
| Motor | Armored Aluminum Motor |
| Anion/Lonizer Function | √ |
| Pre-cooling Function Cushions | Sides And Rear Armored(Evaporative Panesl on Side and Rear Taps Anti-Dust Filter Screens on Covers) |
| Grid Protector | √ |
| Drain Type | Automatic |
| Control System | Remote Control LCD Display With Marker for: Temperature, Speed, Lack of Water, Swing and Lonizer |
| Net Weight(±2kgs) | 31kgs |
| Cushion Dimension Rear (L*H*W) (mm) | 635*670*100 |
| Cushion Dimension Side(L*H*W) (mm) | 495*132*50 |
| Cabinet Dimension (L*W*H) (mm) | 795*978*937 |
Note: The actual airflow is related to the outlet static pressure (air duct resistance).
